CC1300XL SMALL WALK BEHIND SAW

Great for the General Contractor!


14" - 20" Blade Capacity




CC1300XL SMALL WALK BEHIND SAW

More Views

Features & Benefits

  • Heavy duty frame design
  • Cyclone air filter (Honda® models)
  • Easy to maneuver push drive
  • Four position heavy duty handles offer no slack and don't rattle like other adjustable handles
  • Through rear axle for added strength
  • Solid sealed and self aligning blade shaft bearings
  • Slip-on blade guard for easy blade access
  • Three V-belts for extra power delivery to the blade shaft
  • Left or right side sawing
  • Optional water tank available for dust suppression

Specifications

Maximum depth of cut with 14" blade: 4-5/8"
Maximum depth of cut with 18" blade:   6-5/8"
Maximum depth of cut with 20" blade:  7-5/8"
Blade shaft RPM:  2,600
Blade shaft diameter:   1-1/4"
Arbor size:  1" with single drive pin
Blade mounting:  Right or left
Blade raise/lower: Precision screw feed
Handle bars:   Adjustable
 Parts List # (Gas):  1801801
 Parts List # (Electric)  1801809
 Operator Manual #:  1801459
    ◊ Briggs 2100 Series models include a Diamond Products 3-year extended warranty. Horsepower and Torque as rated by the engine manufacturer.



Blade Capacity Engine/Motor Model Motor/Engine Power Engine/Motor Make Power Source Part Number Catalog Number
14" GX270 8.5 HP, 14.1 Torque (lbs.-ft.) Honda® Gas 5800575 75066
14" GX390 11.7 HP, 19.5 torque (lbs.-ft.) Honda® Gas 5800576 75067
14" 2100 420cc, 21 torque (lbs.-ft.) Briggs® ◊ Gas 5801117 61491
14" N/A 5 HP-1PH, 230V Baldor® Electric 5800577 75068
14" N/A 5 HP-3PH, 230V Baldor® Electric 580057A 99977
14” N/A 5 HP, -3PH, 480V Baldor® Electric 5800578B 26493
14" GX390 upcut 11.7 HP, 19.5 torque (lbs.-ft.) Honda® Gas 5800871 27131
18" GX270 8.5 HP, 14.1 Torque (lbs.-ft.) Honda® Gas 5800579 75070
14" 2100 upcut 420cc, 21 torque (lbs.-ft.) Briggs® ◊ Gas 5801118 61493
18" GX390 11.7 HP, 19.5 torque (lbs.-ft.) Honda® Gas 5800571 69995
18" 2100 420cc, 21 torque (lbs.-ft.) Briggs® ◊ Gas 5801116 61494
18" N/A 5 HP-1PH, 230V Baldor® Electric 5800580 75071
18" N/A 5 HP-3PH, 230V Baldor® Electric 5800581A 93652
18" N/A 5 HP, -3PH, 480V Baldor® Electric 5800581B 97080
18" GX390 upcut 11.7 HP, 19.5 torque (lbs.-ft.) Honda® Gas 5800872 26751
20" N/A 10 HP-3PH,230V Baldor® Electric 5800589A 93810
18" 2100 upcut 420cc, 21 torque (lbs.-ft.) Briggs® ◊ Gas 5801119 61496
20" N/A 10 HP-3PH,460V Baldor® Electric 5800589B 93220
20" N/A 10 HP-3PH,230V/460V Baldor® Electric 5800985 57763
20" GX390 11.7 HP, 19.5 torque (lbs.-ft.) Honda® GAS 5800723 21855
20" N/A 15 GPM Danfoss® Hydraulic 5800724A 37387
20" N/A 20 GPM Danfoss® Hydraulic 5800724B 50852
20" N/A 25 GPM Danfoss® Hydraulic 5800724C 37388
