FEATURES
- Hydrostatic ground drive allow precise speed control
- Blade shaft raise/lower switch is incormporated in joystick for ease of operation
- Three-stage engine air intake filter
- Two lights for night grooving
- Right and left side operation positions
- Fuel gauge
- Digital read-out engine control panel includes tachometer and hour meter
Part # BG24DT4, Catalog # 105126
SPECIFICATIONS
| Engine |
Deutz 2.2L, 75HP Tier 4-Final, LIquid-Cooled, Turbo Charged, Common Rail Fuel Injeciton System, 4 Cylinder Diesel Engin, Maximum 2600 RPM |
| Dimensions |
Length: 64-1/2" (163.83cm), Width: 48-5/8" (123.51cm), Height: 59-1/4" (150.49cm) |
| Weight |
3500 lbs. estimated |
| Fuel Capacity |
20 gallons |
| Blade Shaft |
5" (12.7cm), Diameter with key ways |
| Blade Capacity Diameter |
12" (30.48cm) or 14" (35.56cm) |
| Blade Shaft RPM |
Max 1300 RPM |
| Cutting Width |
24: (60.96cm) |
| Blade Shaft Drive |
Belt driven |
| Hydraulics |
Electric over hydraulic adjustable blade raise/lower |
| Ground Drive |
Belt driven hydrostatic ground drive pump |
| Machine Controls |
Control lever connected to transmission controls the ground drive and machine rasie/lower functions |
| Instrumentation |
Digital engine panel |
| Electrical |
12 volt electrical system |
