CP74D Hydraulic Power Unit

Diesel Powered

Export List As PDF

CP74D Hydraulic Power Unit

More Views

Features & Benefits:

  • 74hp Tier 4 Final Deutz TD2.9L4 Liquid Cooled, Turbocharged Common Rail Diesel Engine
  • DVERT Oxidation Catalyst (DOC), Maintenance-free operation.
  • Fully Adjustable 1-35 Gallon per Minute Hydraulic Flow Rate
  • 3000 PSI Maximum Pressure Setting
  • Completely Enclosed, Self Contained Design
  • On board 17 gallon diesel fuel cell
  • 44 Gallon hydraulic reservoir

Integrated safety features including warnings and shutdown commands to protect power pack including:

  • Low Hydraulic Fluid Indicator
  • Hydraulic Fluid Over Temperature Indicator
  • Clogged or Dirty Hydraulic Filter Indicator
  • Standard Engine Controls ( Low Oil Pressure, Coolant Over Temperature, ETC)

Local or Remote Operations, via Wireless Controller

  • Murphy PV450 Color Display digitally indicated all necessary engine information, hydraulic system information and maintenance information.
  • Kar-Tech Wireless Control System, with 2 Line MEGA Series Remote Display that indicates System Pressure and Hydraulic Flow, allows for flow and pressure adjustments, hydraulic function ON/OFF, and Emergency Stop.
  • Charges Directly off the Power unit via the incorporated docking station/charger.

Length : 74”
Width : 30”
Height : 60”
Weight : 2200 lbs (Including Hydraulic Fluid)

Part # 5801545, Cat # 60687

Additional Information

Model Group CB
Model Number CB74D
Catalog Number 60687
Part Number 5801545
Engine/Motor Make No
Engine/Motor Model No
Motor/Engine Power 74 HP
Power Source Diesel
