CC190PRO-EE First-Cut Saw

CC190PRO-EE First-Cut Saw


Part of the First-Cut line of True Early Entry™ products.


14" Blade Capacity


Gasoline Powered

Export List As PDF

CC190PRO-EE First-Cut Saw

More Views

  • CC190PRO-EE First-Cut Saw side elevation
  • CC190PRO-EE First-Cut Saw top view

14" Blade Capacity / Gasoline

Features & Benefits:

  • Maximum cutting depth of 3-1/2” with 14” blade
  • Capable of .110” to .250” thick blades
  • Self propelled drive • Heavy duty handle design
  • Self aligning blade shaft bearings
  • Easy access to battery with heavy duty isolator switch to prevent power drain
  • Up-cut design to keep debris from going back in the cut
  • Lifting hook for easy transport

Specifications:

Blade shaft RPM: 3,500
Blade shaft diameter: 1-1/4”
Arbor Size: 1” with single drive pin
Blade raise/lower: Electric actuator
Transmission:  Eaton Model 6
Drive Speed:  0-80 feet per minute
Handle bars:  Adjustable, raise/lower
Includes:  Electric start, low oil alert and tach/hour meter

Additional Information

Model Group No
Model Number No
Catalog Number 81211
Part Number 5801048
Engine/Motor Make No
Engine/Motor Model No
Sawing Engine/Motor Model GX630
Motor/Engine Power No
Power Source No
Power Source Gasoline
Blade Capacity 14"
