CC2525KCP Propane Saw - CC2500 - Walk Behind Saw - Sawing - Products
<<

CC2525KCP Propane Saw

Clean, Powerful and Compact


14" / 20" / 26" Blade Capacity





Export List As PDF

CC2525KCP

More Views

  • CC2525KCP

Features & Benefits

  • Kohler Command EFI engine converted to propane vapor draw
  • Rigid high strength 3/16" steel box frame with heavy bar reinforcement
  • Two-position tilt handlebars
  • Self-propelled drive for easy cutting
  • Screw feed raise and lower with optional power raise and lower
  • Cyclone air filter
  • Positive gear drive to the rear axle via Eaton hydrostatic transmission
  • Fits through a 30" door frame
SPECIFICATIONS
Max Depth of Cut with 14" Blade 4-3/8"
Max Depth of Cut with 20" Blade 7-3/8"
Max Depth of Cut with 26" Blade 10-3/8"
Blade Shaft Diameter Varies
Arbor Size 1" with single drive pin
Blade Shaft Drive 5 belts
Blade Mounting Right or left
Transmission Eaton Model 6
Drive Speed 0-130 feet per minute
Fuel Tank Size 20 pound
CC2525KCP PROPANE WALK BEHIND SAW
Model # Engine Make/Model Engine Power Blade Capacity Part # Cat # Weight (lbs.)
CC2525KCP-14  Converted Kohler Command EFI  25 HP 14" 5801441 101515 980
CC2525KCP-20 Converted Kohler Command EFI 25 HP 20" 5801442 101516 1,030
CC2525KCP-26 Converted Kohler Command EFI 25 HP 26" 5801443 101517 1,060



Additional Information

Model Group No
Model Number No
Catalog Number No
Part Number No
Engine/Motor Make No
Engine/Motor Model No
Sawing Engine/Motor Model No
Motor/Engine Power No
Power Source No
Power Source No
Blade Capacity No
